Smart Home Compatible with Voice Control
The Onkyo TX-NR5100 7.2-Channel 8K SMART AV Receiver easily integrates into your existing Smart Home ecosystem, including Apple Airplay, Alexa, Google apps, and more. You get a highly capable and compatible network device that can operate seamlessly in your multi-room ecosystem.* *Requires third-party AI compatible smart home device with microphone
HDMI(R) 2.1 with 8K
HDMI (R) 2.1 is the most recent update of the HDMI (R) spec and supports eARC, a range of higher video resolutions and refresh rates including 8K60 and 4K120, and Dynamic HDR formats. 8K delivers a super-immersive viewing experience with 2x the horizontal and vertical resolution of 4K, and 4 times as many pixels; and combined with 60Hz refresh rate enables smooth and sharp viewing of content with high-speed action. HDMI 2.1 with 8K and eARC ensures your system is ready for the clearest and cleanest picture available both now and down the road.
Ultimate 4K Gaming Experience
4K/120 enables ultra-fast motion UHD images to be crisp and razor-sharp; and sports, action movies, and high-performance gaming benefit significantly.
- Smart Home Compatible with Voice Control
- The Onkyo TX-NR5100 7.2-Channel 8K SMART AV Receiver easily integrates into your existing Smart Home ecosystem, including Apple Airplay, Alexa, Google apps, and more. You get a highly capable and compatible network device that can operate seamlessly in your multi-room ecosystem.* *Requires third-party AI compatible smart home device with microphone
- HDMI(R) 2.1 with 8K
- HDMI (R) 2.1 is the most recent update of the HDMI (R) spec and supports eARC, a range of higher video resolutions and refresh rates including 8K60 and 4K120, and Dynamic HDR formats. 8K delivers a super-immersive viewing experience with 2x the horizontal and vertical resolution of 4K, and 4 times as many pixels; and combined with 60Hz refresh rate enables smooth and sharp viewing of content with high-speed action. HDMI 2.1 with 8K and eARC ensures your system is ready for the clearest and cleanest picture available both now and down the road.
- Ultimate 4K Gaming Experience
- 4K/120 enables ultra-fast motion UHD images to be crisp and razor-sharp; and sports, action movies, and high-performance gaming benefit significantly.
| Features | |
| PRODUCT HIGHLIGHTS | |
| 5.2.2-ch Dolby Atmos® and DTS: X® playback | |
| Dolby Atmos Height Virtualizer and DTS Virtual:X™ 3D sound virtualization technologies | |
| SMART AV Receiver™ | Works with Sonos (sold separately), Chromecast built-in™, AirPlay 2, and DTS Play-Fi®; includes Spotify®, Amazon Music HD, Alexa, Pandora®, TIDAL, Deezer, and TuneIn streaming services |
| Works with Hey Google or Alexa* | Digital Voice Assistant Sold Separately |
| Stream Capability | 5 GHz/2.4 GHz dual-band Wi-Fi® supporting the 802.11ac standard |
| HDMI® 2.1 | Supports: 4K120AB and 8K60B, HDR10+, Dolby Vision and BT.2020 color; VRR (Variable Refresh Rate), ALLM (Auto Low Latency Mode), and QFT (Quick Frame Transport); eARC (Main Out), and HDCP 2.3 |
| HDMI Sub Out | For media transmission to a projector, gaming monitor, or TV |
| Send or receive audio via Bluetooth® wireless technology (RX mode: SBC/AAC, TX mode: SBC/Qualcomm® aptX™/ aptX HD) | |
| Zone B pre-/line-out plays MAIN Zone audio to a compatible headphone dock | |
| Vocal Enhancer, media info and playback status display, and one-touch volume memory-preset functions | |
| AccuEQ with AccuReflex™ and subwoofer EQ | |
| Specs | |
| AMPLIFIER | |
| Power output (All channels) | 80 W/Ch (8 ohms, 20 Hz-20 kHz, 0.08% THD, 2-ch driven, FTC) |
| THD+N (Total Harmonic Distortion + Noise) | 0.08% (20 Hz-20 kHz) |
| Input sensitivity and impedance | 200mVrms/32k-ohms (Line) |
| Rated RCA output level and impedance | 1Vrms 200m Vrms/2.2k-ohms Zone B PreLine-out |
| Frequency response | 10 Hz-100 kHz/+1 dB, -3 dB (Direct/Pure Audio) |
| Tone control | 10 dB, 20 Hz (Bass) 10 dB, 20 kHz (Treble) |
| Signal-to-noise ratio | 106 dB (Line, IHF-A) |
| Speaker impedance | 4-16 ohms |
| TUNER | |
| FM | 87.5 MHz-107.9 MHz |
| AM | 530 kHz-1,710 kHz |
| FM/AM preset memory | 40 stations |
| GENERAL | |
| Power supply | AC 120 V~, 60 Hz |
| Power consumption (operating) | 490 W |
| Power consumption (idle) | 45 W |
| Power consumption (standby) | 0.1 W |
| Dimensions (W x H x D) | 17 1/8 x 6 5/16 x 12 15/16 (435 x 160 x 328 mm) |
| Weight | 18.5 lbs. (8.4 kg) |
| UPC Code | |
| UPC | 889951003564 |
| CARTON | |
| Dimensions (W x H x D) | 20 11/16 x 9 7/16 x 15 15/16 (525 x 240 x 405 mm) |
| Weight | 23.1 lbs (10.5kg) |
| ACCESSORIES INCLUDED | |
| Indoor FM antenna | Yes |
| AM loop antenna | Yes |
| Speaker setup microphone | Yes |
| Quick Start Guide | Yes |
| Remote control | Yes |
| Two AAA (R03) batteries | Yes |
The Onkyo TX-NR5100 7.2-Channel 8K AV Receiver is an affordable and versatile home theater centerpiece tailored to deliver a best-in-class entertainment experience for your movies, music, and next-gen gaming systems.
Products specifications
| WiFi Connected | No |
