Self-clean oven
Cleans the oven cavity without the need for scrubbing
Sensi-temp technology
Enjoy the same cooking power as a traditional coil with an added safety feature that meets the new UL858 Household Electric Ranges Standard for Safety
- Self-clean oven
- Cleans the oven cavity without the need for scrubbing
- Sensi-temp technology
- Enjoy the same cooking power as a traditional coil with an added safety feature that meets the new UL858 Household Electric Ranges Standard for Safety
- Chrome drip bowls
- Contain spills and remove for easy cleaning
- Electronic clock and timer
- Help cooks coordinate meal preparation and cooking
| CAPACITY | |
| Total Capacity (cubic feet) | 3 cu ft |
| APPEARANCE | |
| Oven Door Features | Big View Oven Window Glass Door |
| Handle | Designer Style |
| Installation | Flush Appearance |
| Control Knobs | Color-Matched |
| Handle Design | D-shaped |
| Handle Color | Black |
| Color Appearance | Black |
| POWER / RATINGS | |
| KW Rating at 240V | 10.6 |
| Bake Wattage | 2000W |
| Electrical Requirements | 208/240V ; 60Hz ; 40A |
| Amp Rating at 208V | 40 |
| Broiler Wattage | 3400W |
| Hertz | 60 |
| KW Rating at 208V | 8.0 |
| Amp Rating at 240V | 40 |
| WARRANTY | |
| Labor Warranty | Limited 1-year entire appliance |
| Parts Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
| WEIGHTS & DIMENSIONS | |
| Net Weight | 104 lb |
| Depth Without Handle | 24.1875 in |
| Oven Interior Dimensions (W x H x D) (in.) | 19 x 15 x 18 |
| Cooktop Width | 27.125 in |
| Depth with Door Open | 44.1875 in |
| Cabinet Opening | 27 in |
| Cabinet Width | 27 in |
| Approximate Shipping Weight | 124 lb |
| Overall Width | 27.125 in |
| Overall Depth | 27.1875 in |
| Overall Height | 28.4375 in |
| FEATURES | |
| Element - Right Front | 6" 1250W 4-turn |
| Oven Features | 4-Pass Bake Element 4-Pass Broil Element |
| Removable One-Piece Drip Bowls | Chrome |
| Interior Oven Light | 1 Incandescent |
| Fuel Type | Electric |
| Oven Interior | Gray |
| Oven Control Features | Audible Preheat Signal Auto Oven Shut-Off Delay Bake Option (Time Bake) Electronic Clock and Timer |
| Cooktop Burner Type | Coil |
| Oven Rack Features | 2 Oven Racks |
| Element - Left Front | 8" 2400W 5-turn |
| Oven Cleaning Type | Self-Clean |
| Product Type | Drop-In |
| Heating Element "ON" Indicator Light | Yes |
| Cooktop Type | Coil |
| Element - Left Rear | 6" 1250W 4-turn |
| Element - Right Rear | 6" 1250W 4-turn |
| Cooktop Surface | Lift-Up Overhanging Cooktop Porcelain Enamel |
| Control Location | Front |
| Oven Rack Positions (Single or Upper/Lower) | 4 |
| Control Type | Digital Temperature Display Electronic Touchpads |
| Self-Clean Oven Door Lock | Automatic |
| Cooking Technology | Traditional |
Cleans the oven cavity without the need for scrubbing
Sensi-temp technology
Enjoy the same cooking power as a traditional coil with an added safety feature that meets the new UL858 Household Electric Ranges Standard for Safety
Chrome drip bowls
Contain spills and remove for easy cleaning
Electronic clock and timer
Help cooks coordinate meal preparation and cooking
Products specifications
| Width | 27.13, 27.12 |
| Color | BLACK |
| WiFi Connected | No |
| Number of Elements | 4 |
| Height | 28.44 |
| Depth | 27.19 |
