Features:
-
Built-in WiFi powered by SmartHQ™
-
True Built In Design The ultimate fit & finish for more usable space and the best in built-in installation. Sleeve and chassis are perfectly integrated, creating a seamless fit without leaks or gaps
-
Premium Guard Seacoast Protection Premium Seacoast Protection on heat/cool models has special coatings and double coats of paint on key components including coils, base pan, compressor and stainless screws
-
Premium Finish Bright, clean color & a decorative metallic silver accent encasing the air discharge louver, provide an overall sleek appearance
-
Electronic Cap Touch Controls Controls offer a high-end and smooth to-the-touch panel
-
Large LCD Auto-Dimming Display Intuitive & large white LCD display can be easily seen from anywhere in the room. Convenient Auto-Dimming feature provides ambient lighting during the night
-
Slim Room Front A slim room front provides more usable space in the room. It’s the sleekest design in the industry
-
ECO Mode Innovative mode where the fan cycles off during cooling intervals, creating energy savings while keeping the room comfortable
-
Dry Mode Designed for humid environments, it helps provide a dryer & more comfortable atmosphere with room-air dehumidification
-
Auto Mode Automatically select heating or cooling mode and fan speed to maintain the current temperature setpoint. It monitors the room temperature for optimal comfort
-
3-Speed Fan Select High, Medium, Low or Auto Setting to achieve the best in air comfort & ultimate flexibility. Available on heat-cool models
-
6-Way Directional Airflow Direct where the air flows with up to 6 directional vents—cooling and/or heating the areas of the room that need it the most
-
Washable Filter Easy to remove and rinse clean, the filter helps remove dust and other particles from transmitting in the air—providing a cleaner environment
-
Remote Control Included Slim, intuitive and easy to use, the remote control enables adjusting temperatures and settings conveniently from anywhere in the room
-
Quiet Performance Designed & engineered by GE Appliances for ultra-quiet comfort
Specs:
| Wall Case | RAB46/47/48/26 Required At Additional Cost |
| Color Appearance | Soft Gray |
| Installation | Wall Mounted |
| Cooling BTUH (MAX) | 10,000 Btu |
| Cooling BTUH (MIN) | 9,800 Btu |
| Dehumidification (pts./hr.) | 2.7/2.7 |
| Heating - Electric - BTUH - AHAM - 1R | 10600/8600 |
| Air Discharge | Over / Under |
| Airflow (cfm) Roomside | 285/245, 275/235 |
| Chassis Type | Slide-In |
| Connected Capabilities | Amazon Alexa Google Home |
| Control Type | Electronic |
| Cord Length | 68" |
| Fan Speed Selections | 3 Cooling 3 Fan Only |
| Filter Type | Rigid Frame Tilt-Out Washable |
| Heating - Electric - Input Watts | 3470/2850 |
| Louver Style | 6-Way |
| Optional Grill | RAG13/RAG13A/RAG14E |
| Outdoor Vent / Exhaust | Yes |
| Plug Type | Perpendicular/Right Angle LCDI |
| Product Type | Built-In |
| Refrigerant Type | R32 |
| Remote Control | Yes |
| Room Air Conditioner Features | Smart Fan Switch Remote Control Batteries Included Improved Corrosion Package |
| Rotary Compressor | Yes |
| Style | Thru-Wall |
| Temperature Range | 60->85 F |
| Thermostat Type | Electronic Digital |
| Unit Type | Heat / Cool Unit |
| WiFi Connect | Built-In |
| CEER | 9.6/9.6 |
| Cooling - Rated Cooling Amps AHAM | 4.6/5.1 |
| Cooling - Watts | 1030/1010 |
| Heating - Electric - Heater Amps | 15.1/14.0 |
| Hertz | 60 |
| Voltage (MAX) | 230 V |
| Voltage (MIN) | 208 V |
| Voltage/Hertz/Phase | 230-208/60/1 |
| Volts/Hertz | 230V-208V/60Hz |
| Labor Warranty | Limited 2-year entire appliance Limited 5-year sealed system |
| Parts Warranty | Limited 2-year entire appliance |
| Warranty Notes | See written warranty for full details |
| Approximate Shipping Weight | 81 lb |
| Depth to Louvers | 5 in |
| Net Weight | 81 lb |
| Overall Depth | 21.8125 in |
| Overall Depth (Excludes Sleeve) | 19.90625 in |
| Overall Height | 15.625 in |
| Overall Height (Excludes Sleeve) | 14.875 in |
| Overall Width | 26 in |
| Overall Width (Excludes Sleeve) | 24.8125 in |
| BTU Ribbons | 10,000 BTU Ribbon |
