Generous Capacity
PERFECT RESULTS Generous Capacity Two independently operating cavities provide a large total capacity of 4.8 cu. ft. in the main cavity and 2.1 cu. ft. in the secondary. That s enough room for a 32 lb turkey in one oven, and your sides in the other.
Cooking Flexibility
PERFECT RESULTS Cooking Flexibility No matter what you're cooking, you've got the right heat to get perfect results. Each of the 15 oven functions in the main cavity and 11 in the secondary have been extensively researched and carefully designed to cater to a broad range of dishes and cooking styles. The handy food probe helps you monitor your progress.
Cooktop Power
PERFECT RESULTS Cooktop Power On the gas side of the cooktop, Sealed dual flow burners deliver power up to 23,500 BTU, while the induction side delivers up to 3700W. This finely tuned cooktop provides instant and immediate control from the highest heat to the most gentle simmer.
Design Quality
This range has craftsmanship in every detail, with real stainless steel, high-quality glass, and beautifully weighted, halo illuminated dials. Each cavity features incandescent lights and full extension telescopic racks. From the robust legs to the powerful cooktop, this Range is built to last.
Easy To Clean
BEAUTIFUL TO USE Easy To Clean The oven features a self-cleaning function and self-clean proof side racks, which don't need to be removed when using this function. The induction zones only need a quick wipe after use to keep them clean.
- Cook With Confidence
- Our touchscreen interface provides an intuitive guided cooking experience that helps deliver perfect results, whether you ve been cooking all your life or just starting out. Cook with a favorite method, a hero ingredient, or a go-to cooking function or recipe. The screen tilts for improved ergonomics and optimal visibility while cooking.
- Generous Capacity
- Two independently operating cavities provide a large total capacity of 4.8 cu. ft. in the main cavity and 2.1 cu. ft. in the secondary. That s enough room for a 32 lb turkey in one oven, and your sides in the other.
- Cooking Flexibility
- No matter what you're cooking, you've got the right heat to get perfect results. Each of the 15 oven functions in the main cavity and 11 in the secondary have been extensively researched and carefully designed to cater to a broad range of dishes and cooking styles. The handy food probe helps you monitor your progress.
- Cooktop Power
- On the gas side of the cooktop, Sealed dual flow burners deliver power up to 23,500 BTU, while the induction side delivers up to 3700W. This finely tuned cooktop provides instant and immediate control from the highest heat to the most gentle simmer.
- Design Quality
- This range has craftsmanship in every detail, with real stainless steel, high-quality glass, and beautifully weighted, halo illuminated dials. Each cavity features incandescent lights and full extension telescopic racks. From the robust legs to the powerful cooktop, this Range is built to last.
- Easy To Clean
- The oven features a self-cleaning function and self-clean proof side racks, which don't need to be removed when using this function. The induction zones only need a quick wipe after use to keep them clean.
| Accessories (included) | |
| Adjustable feet covers | âĸ |
| Branded coin end cap | âĸ |
| Accessories (sold separately) | |
| Dial kit Professional, Brass | ADLP3RH484BA |
| Dial kit Professional, Dark Copper | ADLP3RH484DC |
| Burner ratings | |
| Maximum burner power | 23500 BTU |
| Power back left | 18500BTU |
| Power back right | 18500BTU |
| Power front left | 23500BTU |
| Power front right | 18500BTU |
| Total cooktop power | 79000 BTU |
| Capacity | |
| Shelf positions (main oven) | 5 |
| Shelf positions (second oven) | 5 |
| Total capacity (main oven) | 4.8cu ft |
| Total capacity second oven | 2.1cu ft |
| Usable capacity (main oven) | 3.8cu ft |
| Cleaning | |
| Easy clean porcelain basepan | âĸ |
| Pyrolytic self-clean | âĸ |
| Controls | |
| Dial with illuminated halo | âĸ |
| Dual control oven dials | âĸ |
| Electric circuit | 4 wire |
| High resolution display | âĸ |
| Metal illuminated dials | âĸ |
| Multi-language interface | âĸ |
| Precise cooking with food probe | âĸ |
| Recipe and food based functions | âĸ |
| Sabbath mode | âĸ |
| Smart Appliance | âĸ |
| Tilting touch screen interface | âĸ |
| Gas Requirements | |
| Fitting and pipe | 1/2 NPT, min. 5/8 " flex line |
| Supply Pressure (natural gas) | 6 " to 9" W.C |
| Oven features | |
| Auto re-ignition system | âĸ |
| Concealed element | âĸ |
| Electronic oven control | âĸ |
| Full extension telescopic sliding shelves | âĸ |
| True convection | âĸ |
| Oven functions | |
| Air fry | âĸ |
| Bake | âĸ |
| Classic bake | âĸ |
| Clean | âĸ |
| Convection bake | âĸ |
| Convection broil | âĸ |
| Maxi broil | âĸ |
| Number of functions | 15 |
| Pastry bake | âĸ |
| Pizza bake | âĸ |
| Rapid proof | âĸ |
| Roast | âĸ |
| Slow cook | âĸ |
| True convection | âĸ |
| Warm | âĸ |
| Oven performance | |
| Bake | 4600W |
| Broil | 3600W |
| Broil power | 4000W |
| Main oven - True convection power | 2500W |
| Power requirements | |
| Connection | 4-prong grounding type [NEMA 14-50P plug] |
| Service | 50 A |
| Supply frequency | 60Hz |
| Supply voltage | 208 - 240V |
| Product dimensions | |
| Depth | 29 1 / 8 " |
| Height | 35 3 / 4 - 36 3 / 4 " |
| Width | 47 7 / 8 " |
| Rangetop features | |
| Gentle heat | âĸ |
| Heat settings | 9 |
| Induction cooking technology | âĸ |
| Sealed range top | âĸ |
| SmartZone | 2 |
| Vent trim included | âĸ |
| Zone bridging | âĸ |
| Rangetop Performance | |
| Left front zone rating | 2100 (3700)W |
| Left rear zone rating | 2100 (3700)W |
| Number of cooking zones | 4 |
| PowerBoost | âĸ |
| PowerBoost all zones | up to 3700W |
| Right front zone rating | 2100 (3700)W |
| Right rear zone rating | 2100 (3700)W |
| Recommended Back Guards Ventilation | |
| Combustible situation | BGRV3-3048H |
| Non combustible situation | BGRV2-3048 / BGRV2-1248 |
| Recommended hood | HCB48-12_N (48 " Professional Range Hood, Dual Blower) |
| Safety | |
| ADA compliant | âĸ |
| Pan detection system | âĸ |
| Safety time out | âĸ |
| Surface hot indicators | âĸ |
| Secondary oven features | |
| 3/4 Extension racks | 2 |
| Electronic oven control | âĸ |
| Food probe | âĸ |
| Internal light | âĸ |
| Secondary oven functions | |
| Air fry | âĸ |
| Bake | âĸ |
| Classic bake | âĸ |
| Convection bake | âĸ |
| Convection broil | âĸ |
| Maxi broil | âĸ |
| Number of secondary oven functions | 11 |
| Pastry bake | âĸ |
| Pizza bake | âĸ |
| Rapid proof | âĸ |
| Roast | âĸ |
| Warm | âĸ |
Products specifications
| Color | STAINLESS STEEL |
| WiFi Connected | No |
| Burner Type | Sealed |
| Number of Burners | 4 |
