Product Recommendations
Generous Capacity
PERFECT RESULTS Generous Capacity Featuring a generous total capacity of 5.3 cu ft, with enough room to fit a 32 lb turkey and full-sized baking sheets.
Cooktop Power
PERFECT RESULTS Cooktop Power Sealed Dual Flow Burners(TM) deliver cooktop power up to 23,500 BTU for seriously fast boiling right down to a precise 140(degree)F full surface simmer with the gentlest of flames.
Cooking Flexibility
BEAUTIFUL TO USE Cooking Flexibility The cooktop is designed for easy access to any burner with grates you can smoothly slide pots across. The oven is large enough to hold full size baking sheets.
Design Quality
BUILT TO LAST Design Quality This range has craftsmanship in every detail, with real stainless steel, cast-iron grates, and titanium coated dials. Each cavity features incandescent lights and full extension telescopic racks. From the robust legs to the powerful legs to the powerful cooktop, the Range is built to last.
Easy To Clean
BEAUTIFUL TO USE Easy To Clean Cleaning up spills is effortless with the continuous, porcelain basepan. Your cooktop simply needs a quick wipe to keep it looking good as new.
Total Control
BEAUTIFUL TO USE Total Control Precise control across high and low settings is delivered through the halo-illuminated cooktop dials.
- Generous Capacity
- Featuring a generous total capacity of 5.3 cu ft, with enough room to fit a 32 lb turkey and full-sized baking sheets.
- Cooktop Power
- Sealed Dual Flow Burners(TM) deliver cooktop power up to 23,500 BTU for seriously fast boiling right down to a precise 140(degree)F full surface simmer with the gentlest of flames.
- Cooking Flexibility
- The cooktop is designed for easy access to any burner with grates you can smoothly slide pots across. The oven is large enough to hold full size baking sheets.
- Design Quality
- This range has craftsmanship in every detail, with real stainless steel, cast-iron grates, and titanium coated dials. Each cavity features incandescent lights and full extension telescopic racks. From the robust legs to the powerful legs to the powerful cooktop, the Range is built to last.
- Easy To Clean
- Cleaning up spills is effortless with the continuous, porcelain basepan. Your cooktop simply needs a quick wipe to keep it looking good as new.
- Total Control
- Precise control across high and low settings is delivered through the halo-illuminated cooktop dials.
| Burner ratings | |
| Maximum burner power | 23500 BTU |
| Power back centre | 18500BTU |
| Power back left | 18500BTU |
| Power back right | 18500BTU |
| Power front centre | 18500BTU |
| Power front left | 23500BTU |
| Power front right | 23500BTU |
| Total cooktop power | 121000 BTU |
| Capacity | |
| Shelf positions | 5 |
| Total capacity | 5.3cu ft |
| Usable capacity | 4cu ft |
| Controls | |
| Electric circuit | 3 wire |
| Metal illuminated dials | • |
| Gas Requirements | |
| Fitting and pipe | 1/2 NPT, min. 5/8 " flex line |
| Supply Pressure (natural gas) | 6 " to 9" W.C |
| Oven features | |
| Auto re-ignition system | • |
| Broil pan | • |
| Electronic oven control | • |
| Full extension telescopic sliding shelves | • |
| Infrared Broiler | • |
| Titanium coated, illuminated metal dials | • |
| Oven functions | |
| Bake | • |
| Broil | • |
| Convection bake | • |
| Number of functions | 4 |
| Slow cook | • |
| Oven performance | |
| Bake power | 28000 |
| Broil power | 18500W |
| Power requirements | |
| Service | 15 A |
| Supply frequency | 60Hz |
| Supply voltage | 120V |
| Product dimensions | |
| Depth | 29 1 / 8 " |
| Height | 35 3 / 4 - 36 3 / 4 " |
| Width | 35 7 / 8 " |
| Rangetop features | |
| Sealed range top | • |
| Vent trim included | • |
| Recommended Back Guards Ventilation | |
| Combustible situation | BGRV3-3036H |
| Non combustible situation | BGRV2-3036 / BGRV2-1236 |
| Recommended hood | HCB36-6_N (36 " Professional Range Hood) / HCB36-12_N (36" Professional Range Hood, Dual Blower) |
| Safety | |
| ADA compliant | • |
| Full extension telescopic sliding shelves | • |
Finish Stainless Steel Fuel Type Natural gas
Products specifications
| Color | STAINLESS STEEL |
| WiFi Connected | No |
| Burner Type | Sealed |
| Number of Burners | 6 |
